Scan Antenna IOT868 low profile 868Mhz ISM band 1.5m

The slim design with integrated cable, where cable length and connector can be specified at time of order, gives a high grade of flexibility in installation projects, where time is of essence.



The look is designed to be as unobtrusive as possible when mounted in the utility room.



Place it vertically outdoors with the cable downwards – a simpler installation of a high performing antenna is difficult to get.

248,98  DKK

All prices are excl. VAT

Product no. 48001-011 Category

Out of stock
Place order and complete checkout. We provide the leadtime within 24 hrs.

IOT868-ScanAntenna Wall Mounted Low Profile IOT Antenna

Slim IOT/M2M antenna designed for e.g. LoRa, Sigfox and Wireless M-Bus technologies

Especially made for the 868 MHz ISM band

1.5 m RG174 cable + SMA-male (Polybag)

Easy mounting on vertical surfaces

Simple and discreet design

No ground plane needed

Frequency: 860 – 876 MHz (ISM and other adjacent bands)

Bandwidth: 16 MHz

Weight 0,08 kg
Weight (kg)

Cable

Impedance

Frequency

dangerousgoods

Gain

Material

Polarisation

Mounting

Connection 1

Brand

Max. Power

Operation temp. (°C)
